High-grade carbon layup
The CF SLX combines the cutting-edge innovations of the CFR platforms with an advanced carbon layup that strikes the ideal balance between lightness and durability by using a specially engineered high-end fibre mix.
An all-new, adjustable and adaptable cockpit
As well as interchangeable drops, our groundbreaking CP0048 Aerocockpit places a wide range of fine fit adjustments and gear integration options in your hands. Dialling in your fit is precise and fast, with 20 mm of height and 50 mm of width adjustment with no cutting required. Plus, the new Gear Groove interface provides a solid platform for mounting a range of accessories quickly, from aero bars to computer mounts (available separately).
PACE - Performance Adaptive Cockpit Ecosystem
From more upright and comfortable to low and aero, switch between cockpit setups in minutes using the Ultimate's interchangeable drops. As standard, the Ultimate uses the more balanced Classic Drops – with narrower Aero Drops available as an aftermarket extra for a slammed, compact, pro-inspired riding position with a longer effective reach.
Aerodynamically optimised
On the road, from just 14 kph, aerodynamic drag is the largest force holding you back. So we optimised the frame forms for minimum drag, through an exhaustive process of wind tunnel testing in collaboration with aero experts Swiss Side. We also integrated the headtube/fork area as much as possible for extra aero gains.
A watt-saving, comfortable carbon aero seatpost
The Ultimate looks even cleaner and sleeker with this clamp design. The clamp is hidden away in the seat tube, so there’s no extra drag. We combine it with a D-shaped seatpost to reduce air resistance in the seat tube area to an absolute minimum. Plus, it’s also simple to adjust so you can easily find your perfect riding position thanks to independent setback and tilt adjustment.
An integrated tool for adjustments on the go
The Ultimate's removable through axle lever doubles up as a TX25 tool that fits almost every screw across the bike, and clips discreetly into the wheel when not in use. One simple tool that you can use for any emergency adjustment on the road. Please note: the tool is meant for emergency adjustments only. The user is responsible for following the specified torque values when tightening bolts, which cannot be checked with the tool.
SPECIFICATION :
Frame | Canyon Ultimate CF SLX, Our latest 5th-generation Ultimate frame. Axle dimension: 12x142 mm, Tyre clearance: 33 mm, Material: Carbon (CF), Weight: 885 g |
Fork | Canyon FK0146 CF Disc, Axle dimension: 12x100 mm, Fork steer tube diameter: 1 1/4", Tyre clearance: 33 mm, Material: Carbon (CF), Weight: 367 g |
Battery | Shimano BT-DN300 Di2 Battery |
Rear Derailleur | Shimano Ultegra Di2 RD-R8150 12s, Weight: 260 g |
Front Derailleur | Shimano Ultegra Di2 FD-R8150, Weight: 111 g |
Cassette | Shimano Ultegra CS-R8100, Number of sprockets: 12, Range: 11-34 |
Crank | Shimano Ultegra R8100 4iiii Precision Powermeter 3+, Number of chainrings: 2 |
Bottom Bracket | Shimano Pressfit BB72, Bottom bracket standard: PF 86,5 Weight: 65 g |
Chain | Shimano XT |
Shif-/ Brake Lever | Shimano Ultegra Di2 R8170 12s, Number of pistons: 2, Weight: 369 g |
Shift-/ Brake Lever | Shimano Ultegra Di2 R8170 12s, Number of pistons: 2, Weight: 368 g |
Brake Rotor | Shimano Ultegra RT-CL800, Size: 140 mm, Weight: 95 g |
Brake Rotor | Shimano Ultegra RT-CL800, Size: 160 mm, Weight: 112 g |
Front Wheel | DT Swiss ARC 1400 Dicut, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 38 mm, Inner width: 20 mm, Rim material: Carbon, Weight: 634 g |
Rear Wheel | DT Swiss ARC 1400 Dicut, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 38 mm, Inner width: 20 mm, Rim material: Carbon, Weight: 810 g |
Tyre | Pirelli P Zero Race RS, Width: 28 mm, Weight: 311 g |
Thru Axle | DT Swiss Through Axle, Axle dimension: 12x142 mm |
Thru Axle | DT Swiss Through Axle, Axle dimension: 12x100 mm |
Cockpit | CP0048 100 mm, Aero carbon cockpit with 40 mm width and 15 mm height adjustment for a total of 12 distinct positions. Material: Carbon (CF), Weight: 224 g |
Handlebar Tape | Canyon Ergospeed Gel, Grippy, durable bar tape with a premium, high-quality, comfortable feel. Color: black |
Saddle | Selle Italia SLR Boost Superflow S saddle, Width: 130 mm, Gender: Unisex, Max. Rider Weight: 100 kg, Weight: 181 g |
Seatpost | Canyon SP0094 CF, Comfortable, compliant, lightweight carbon seatpost., Setback: 10 mm, Material: Carbon (CF), Weight: 118 g |
Seat Clamp | Canyon EP2353-01, EP2352-01 Saddle Clamp for saddles with 7x7 mm Carbon rails, Spring |
Pedals | None included |
Manuals and Accessories | Canyon Organza Bag, Canyon Assembly Paste, Canyon Torque Wrench, Canyon starter box, Quick Start Guide |
